Description
Features
Non-dispersive infrared (NDIR) absorption sensor provides high accuracy in a compact, low cost package
Night setback override button shorts the thermistor output when depressed
CO2 measurement range: 0 to 2000 ppm
Accuracy: up to ±30 ppm or 3% of reading
Optional slide potentiometer
Left (stop) 0k Ohms (±5k Ω)
Center 50k Ohms (±7.5k Ω)
Right (stop) 100k Ohms (±15K Ω)
Patented ABC Logic self-calibration system eliminates the need for manual calibration in most applications
Mounting plate with two-piece terminal blocks provide quick, easy wiring
Gas permeable, water resistant CO2 diffusion filter prevents particulate and water contamination of the sensor
Locking screw secures cover and sensor to the mounting bracket for tamper resistance
Dual simultaneous analog outputs (V & mA) available for CO2
Sensors are shipped factory calibrated
Temperature sensor on all models
CE and RoHS compliant
