Description
The Druck 1800 series pressure transmitters are fully submersible, high performance sensor with millivolt or milliamp output for measuring hydrostatic liquid levels. Incorporating many enhanced features, the 1800 series is specifically designed for level and depth measurements in a variety of environments: groundwater, well water, wastewater, seawater, canals, rivers, and other similar applications.
The 1800 series has ranges from 3 ftH2O or 1 psi with a standard accuracy of ±0.10% FS BSL with ±0.06% FS BSL accuracy available. The micro-machined silicon element is sealed within an all-titanium pressure module assembly, fully isolated from the pressure media. This is contained in a slimline, welded titanium body, terminated in an injection molded cable assembly available with polypropylene or Hytrel cable. The cable features a Kevlar® strain cord and is IP68 rated for indefinite immersion in 700 mH2O.
The Druck 1800 series pressure transmitters are designed for easy installation and include a number of options and features to tailor them to your particular application. The combination of a high technology sensor, together with advanced signal conditioning and packaging techniques, provides an ideal long term solution for reliable, accurate and economical level measurements.
Features
Ranges as low as 3ftH2O (1psi)
Call us for custom ranges as high as 1968ftH2O
Gauge or absolute pressures
±0.10% FS BSL accuracy standard
±0.06% FS BSL option available
Fully welded 17.5mm diameter titanium construction
PTX output is 4-20mA, proportional for 0 to FS pressure
PDCR output is 25mV (for 3ftH2O range)
50mV (for 5 and 10ftH2O ranges)
100mV (for 20ftH2O and above)
±0.1% FS per year long-term stability
Temperature compensated from -2 to 30°C (28 to 86°F)
±0.3% FS Temperature Error Band (TEB) (≥10ftH2O)
Vented polyurethane or Hytrel cable
ATEX/IECEx Intrinsic Safety approval (optional)
Lightning surge arrestor (optional)
