Fuji Electric PXF Series VMD Temperature Controllers

Description

The Fuji Electric PXF VMD temperature controllers were developed as successors to the PXG. They are equipped with universal input for RTD, thermocouples, voltage, current, and mV. Switching the input is an easy parameter change.
The PXF series features highly accurate input indication:
RTD is ±0.2% of indication value ±1 digit or ±0.8°C ± 1 digit, whichever is larger
Thermocouple is the larger of ±1°C ±1 digit or ±0.3% of indicated value ±1 digit
Voltage and current are ±0.3% FS ± 1 digit
Features
Position feedback optional on the PXF5 & PXF9
Universal input
Thermocouple, RTD, voltage, current, mV
Improved input indication accuracy, up to ±0.2%
0.1 to 99 second control cycle
PID controls with auto tuning
PID, 2-degrees-of-freedom PID, & fuzzy
Ramp soak function (simple program control)
64 steps x 1 pattern
32 steps x 2 patterns
16 steps x 4 patterns
8 steps x 8 patterns
Directly connect to a PC with optional USB cable
This will bus-power the unit
