Description
Features
Models AT1X and AG1X Thermo-Flo Flow Controllers
Set point range:
AT1X: 0.04 to 3 fps (0.012 to 0.91 mps)
AG1X: 1 to 90 fps (0.3 to 27 mps)
Fail-safe relay control of pumps or valves with 0 to 60 second delay
Pressure rating:
150 psi (10 bar) @ 25°C
derated @ 1.667 psi (0.113 bar) per °C above 25°C
Sensor lengths:
Short: pipe or ducting from 1/2″ to 1 1/2″
Long: pipe or ducting 2″ or higher
Process temp: 32 to 140°F (0 to 60°C)
Response time: 1 to 10 seconds
Repeatability: ±0.5% of set point
LED indication: sensor, power & relay
Polypropylene-Ryton® or PVDF sensor for corrosive liquids & gases
Polypropylene enclosure rated NEMA 4X with swivel base
Invert switch changes relay state from NO to NC without rewiring
