Description
Features
Dual-stage piston: Higher pressure with less effort
Generated Pressure Range: up to 10,000 psi (700 bar)
Adjustment Resolution: 100 Pa (1 mbar)
Maximum load volume: 100 ml
Maximum volume of fine adjustment: 1.5 ml
Port filters:
Standard port: 150μm quick removal filter
Pump air intake port: 100μm quick removal filter
Pressure outlet: 150μm quick release filter
Material:
Ram/adapters: Stainless steel
Body: Stainless steel, aluminum, UPVC
Seals: Buna-N, PTFE, Copper Alloy
Multi-position Versatility
Warranty: 1 year
What’s in the Box
Mineral oil, 1 bottle (250 ml)
O-ring: 20 pcs
Flexible hose (Maximum pressure:720 bar)
ADT100-X-M18M (one female quick connector for DUT) *
Carrying case (997-X-SET models only) *
*X – designated by base model ordered
